Refurbished Siemens MAMMOMAT 3000 Nova Mammography Machine

The MAMMOMAT 3000 Nova combines screening and diagnostic for maximum utilization in one single unit. The ability to integrate with a variety of CR readers makes it easy to upgrade to digital.

Together with syngo Opdima, the digital biopsy and spot imaging system, stereotactic biopsies can be performed within the smallest space. Spot imaging is possible with a resolution of up to 20 lp/mm.

One system. For all women. For all applications.

The motorized, isocentric X-ray tube rotation by up to 180 degrees counterclockwise and 130 degrees clockwise ensures that patients can be examined comfortably in any projection. The object table always remains at the same height, making repositioning almost unnecessary.
The unique pivoting bucky table enables quick and easy switching between 18 cm x 24 cm and 24 cm x 30 cm formats. When the object table is changed, the appropriate collimation is automatically preselected. This makes MAMMOMAT 3000 Nova an optimal system for almost all women and breast sizes.
Like MAMMOMAT 1000, MAMMOMAT 3000 Nova also distinguishes itself through its slim, spacesaving design. It offers optimal access for the physician, technician, and patient in any projection. The large SID of 65 cm allows easy patient positioning and easy mounting of the biopsy unit and magnification table.

High resolution. Low dose. High quality images.

MAMMOMAT 3000 Nova features an X-ray tube which, unlike other mammography systems, uses two different anode materials. The Opdose function auto-selects the best kV value and anode/filter combination (Mo/Mo, Mo/Rh, W/Rh) according to the individual breast characteristics in order to achieve optimal image quality with the lowest possible dose. Opdose can provide a dose reduction of up to 60 % – a great advantage particularly for women with dense breast tissue. The resulting images are of convincing quality and retakes are reduced to a minimum.

MAMMOMAT 3000 Nova

Application

• Screening
• Diagnostic
• Stereotactic biopsy

Design

• Small footprint
• Open design
• Isocentric movements
• Pivoting bucky table for switching quickly between different formats

Image quality

• Opdose auto-selects the best anode/filter combination and lowest dose according to individual breast characteristics
• Anode/filter combination with: Mo/Mo, Mo/Rh, W/Rh for reduced dose

Comfort and convenience

• Opcomp for optimal compression with automatic selection of the required pressure
• SoftSpeed reduces the speed of the compression plate as it touches the breast
• Large range of compression plates such as Flex2, which automatically adapts to the breast anatomy
• Easy access for the physician, technician, and patient
• Also suitable for patients in a wheelchair
• Easy to use
• Quickswitch to change cassettes easily within seconds using only one hand

Efficiency

• High patient throughput
• Fast amortization
• One system for almost all applications in mammography
• Prepared for the use of CR readers from different manufacturers
